Rotary Turntable
Positioners
Robot-controlled and designed to maximize your robot capacity
Your parts aren’t flat and static, so why is your welding table?
Rotary welding positioners increase production and uptime while
reducing setup time, scrap rate, and downtime.
Increase Uptime
Dramatically increase your robot arc-on time by loading and welding parts simultaneously.
Weld Larger Parts
Process those parts you turned down before because they were out of the robot’s reach.
Speed Up Your Weld Cycles
Simplify complex part setups and increase your parts per hour.
Kinetic Technologies’ Rotary Turntables put you back in the driver seat. Developed specifically for robotic welders, Kinetic Technologies’ rotary welding positioners are modular and flexible, allowing you to weld large and complex parts.
Why limit your robot welder with a static table? Getting the correct part orientation with manual methods takes time. Setup complexity multiplies with the size and shape of the part. The time you are spending positioning a part is time the robot is not welding! Kinetic Technologies’ welding turntables solve that for you.
We know you don’t need complicated integrations, long lead times and light-weight solutions. This is why we provide robust, modular products that fit your system needs. We take the complexity out of integration so your team can get back to work.
A Modular Rotary Welding Positioner Family to Match Your Needs
RT1 Welding Turntable
The durable 48″ round table allows you to accurately position parts within 0.01 degrees, rotate while welding, and achieve side-to-side accuracy of 0.005”. Designed for robots with a 51” reach, the RT1 is a URCap & UR+ Certified product with SIL 4 rated PLC. Mechanical features are customizable, such as table grid and robot location.
RT Lite Welding Turntable
Designed as a simple and affordable rotary turntable, the RT Lite provides the same size, weight, and accuracy capabilities as the RT1. The RT Lite does not include the integrated cobot stand, forklift pockets, stainless steel welder housing, or safety scanner.
RT Lite Welding Turntable
Designed as a simple and affordable rotary turntable, the RT Lite provides the same size, weight, and accuracy capabilities as the RT1. The RT Lite does not include the integrated cobot stand, forklift pockets, stainless steel welder housing, or safety scanner.
Welding Turntable Features
RT1
RT Lite
2,000 lbs Weight Capacity
URCap & UR+ Certified
SIL 4 rated PLC
Available with PROFINET, Modbus, EthernetIP, and TCP/IP
Integrated Cobot Stand
Forklift Pockets
Stainless Steel Welder Housing
Discover how the RT Rotary Positioners can revolutionize your welding productivity.
Get More Flexibility with Modular Welding Turntable Positioners
Flexible Servo-driven Infinite Position Rotary Table
- Simple control through a Universal Robots URCAP interface.
- Control table position as precise as 0.01 degrees, accurately locate parts within 0.005”.*
- Optional extendable spine and riser blocks to customize robot location for most effective use.
- Available in SAE or Metric grid fixturing.
Built For Durability
- Durable 48″ round table with FNC finish protects against weld spatter.
- Precision machined components allow you to transfer robotic programs from one table to another.
- Flippable and replaceable table sections maintain surface finish and flatness if damaged or worn.
Integrated Safety
- SIL 4 rated PLC with ample safety inputs allowing for flexible safety/cell design
- Laser safety scanner available, eliminating the need for clumsy safety cages
Integrates with Multiple Robot/Cobot Brands
- URCap & UR+ Certified product.
- Can support a wide range of robots and communication protocols
– Profinet, Modbus, EthernetIP and TCP/IP
* Features not available on all robot brands
Featuring the Cobot Welder from Hirebotics
RT Positioner Specifications
Weight Capacity
• Table Load: 2,000 lbs
• Edge Load: 1,000 lbs (on support arm)
Table Weight
• 1,300 lbs
Power Requirements
• 240V Three Phase, 15A
Tabletop Grid
Configuration
• SAE (standard): 5/8″ hole diameter on 2″ Grid Spacing
• Metric (optional): 16mm hole diameter on 50mm Spacing
Repeatability*
• Individual Table <0.005″
Finish
• Tabletop: Machined finish, FNC heat treated
• Chassis: Rugged powder coat finish
Need Customization?
customizable extensions, risers, overhead gantry attachments,
custom fixtures, tooling, and work-holding solutions.
Request a Quote for our Turntables
