Combine the flexibility of a skyhook positioner with the productivity increase of an indexing positioner. This indexing dual skyhook positioner has a 150kg capacity with a 30” DIA work envelope per station. Load parts safely on one side while the robot performs welds on the opposing side.
At the core is the FANUC ARC Mate 120iD/12L, a 6-axis robot built for arc welding, with a 12 kg payload and extended 2,272 mm reach. Paired with Kinetic’s Skyhook 2-axis positioner, the system handles large, complex parts up to 1,000 kg, with a 72” swing diameter and up to 45” part height.
An intuitive touchscreen HMI simplifies operation and reduces training time. Built-in arc-flash protection and light curtains improve operator safety. With an industrial PC and Allen-Bradley controls, the system integrates reliably into existing production environments.
Specifications
Features
- FANUC Robot / Rockwell Automation Controls / Integrated by Kinetic Technologies
- Load/Unload directly into the weld cell
- Maximum weld joint access from 2 axis positioner
- Easy maintenance and cleanliness
- Side access door for entering in a safe environment
- Recipe Management with room for up to 100 recipes
- Base model is configured to weld steel and hard metals, soft metals require additional option
Power Source Specifications
• PMC (Pulse Multi Control)
• LSC (Low Spatter Control)
• CMT (Cold Metal Transfer)
• RPI / RPI Auto
• SoftStart (touchdown ignition)
• HF ignition / Touch HF ignition
• Stainless steel
• Aluminum (CMT-ready configuration)
• Stainless steel
• Thin-wall steel
• Food-grade materials
• Stainless Steel
• Aluminum
• Nickel
• Flush cutting
• Max control gouging
• Max removal gouging
• Mechanized cutting
• Flush cutting
• Max control gouging
• Max removal gouging
• Mechanized cutting
• Flush cutting
• Max control gouging
• Max removal gouging
• Mechanized cutting
Not sure which power source fits your application?
Our engineers help manufacturers select the right welding process, equipment configuration, and parameters for their specific parts and production requirements.
Custom Production HMI
The touchscreen operator interface designed by Kinetic Technologies simplifies production workflows. Operators can select part programs, manage settings, and monitor system status without relying on the robot teach pendant.
Service Packages
1-Year System Warranty
Onsite installation & Commissioning
- Preventive Maintenance Program
- Robotic Part Programming
- Custom Fixture & Tooling Design and Manufacturing
- Weld Process Development (WPS, WSS, PQR Documentation)
- Production Part Approval Process (PPAP) Support
- FANUC, Fronius, and Lincoln OEM-Certified Training
- Kinetic Technologies Operator and Supervisor/Engineering Training
- Customized Operational Training Programs
